제품사양

■ Product description

폭(Width) 　900mm, 1000mm, 1200mm 두께(Thickness) 　100mm, 50mm, 30mm 길이(Length) 　up to 7,000mm 표면재(skin) 　○ Silicone polyester painted galvanized steel sheet 　○ Polyvinyl fluoride painted galvanized steel sheet 충진물(Core) 　Rigid polyurethane foam 　자기소화성(난연3급) 　Density : 35kg/m3 　Thickness : 30mm~100mm

■ Typical Physical Properties

Description UNIT TEST SPEC 압축강도 Compression Strength 2.1 ~ 3.3kg/㎠ ASTM-D1621 열전도율 Thermal conductivity 0.018kcal/㎡ ASTM-C518 흡수량 Absorption Test 1g/100/㎠ ASTM-D2127 내열성 Flammability Test 25 ASTM-E108 규격안전성 Dimensional Stability ±0.5 ASTM-D2126 충진도 Closed Cell Content 95% ASTM-D1940 신장강도 Tensile Strength 3.0-5.0kg/㎠ ASTM-D1623 굽힘강도 Bending Strength 2.0-5.0kg/㎠ ASTM-D790 전단강도 Shear Strength 2.0kg/㎠ ASTM-C273

■ Kinds of finish coating

Products Coating Method Paints Size P.E-COLOR 폴리에스테르수지 강판 Two-Coat Two Bake Polyester resin Thick:0.20-1.6mm Width:600-1380mm SUN-TEK COLOR 썬텍 칼라 강판 Two-Coat Two Bake Multi-Purpose resin Thick:0.20-1.6mm Width:600-1380mm SI-COLOR 실리콘수지 강판 Two-Coat Two Bake Silicone Polyester resin Thick:0.20-1.6mm Width:600-1380mm PVDF-COLOR 불소수지 강판 Two-Coat Two Bake Poly Vinyidene Fluoride fesin Thick:0.20-1.6mm Width:600-1380mm HI-POLYMER P.E 하이폴리머 폴리에스테르 수지강판 Two-Coat Two Bake Hi-Polymer Polyeste resin Thick:0.20-1.6mm Width:600-1380mm ANTI-STATIC HI-POLYMER P.E 대전방지 칼라 강판 Two-Coat Two Bake Polyester resin Thick:0.45-1.6mm Width:600-1380mm
